| Model No. | eMarvel 225w |
| Product Name | Rigid light solar panel |
| Maximum Power[Wp] | 225 |
| Solar Cell | SunPower Maxeon Gen III Back Contact Cell |
| Cell Array[Pcs] | 6*11 |
| Cell Efficiency | 22.60% |
| Size[mm] | 800*1460*5mm |
| Max Power Voltage Vmp[V] | 19.14 |
| Max Power Current Imp[A] | 11.76 |
| Open Circuit Voltage Voc[V] | 22.59 |
| Short Circuit Current Isc[A] | 12.70 |
| Net.Weight[kg] | 10.00 |
| Power tolerance[%] | ±5% |
| NOCT[℃] | 45±2 |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/K] | -0.3 |
| Temperature Coefficient Voc[[%/K] | -1.74mV |
| Temperature Coefficient Isc[[%/K] | 0.05 |
| Maximum System Voltage[V] | 1000 V |
| Maximum Reverse Current[V] | 10A |
| Flame retardancy | UL94 VTM-0 |
| Certification and test | CE,ROHS,SGS,IEC salt mist,High temp humidity test |
| Surface/Backsheet | Japan ETFE/white plastic |
| Maximum bend radius(θ) | 5° |
| Cables and Connectors | 40cm 2.5mm² cable with MC4 |
| Warranty[Years] | 2 |
| Standard Test Conditions | STC: 1000W/m², AM 1.5 and cell temp 25°C |
| Other notes | round corner R10,with silicon back up holes |
| Package | 1pcs/Polyethylene foam(EPE Foam),then in 1 carton box |
